Product benefits
- Flat housing design to minimize dust accumulation and easy cleaning
- Optimized weight and size due to compact design
- Multiple adjustments of sensor range, daylight detection and hold time
- Suitable for use in dusty and damp locations thanks to high IP rating
- Energy savings of up to 70 % compared to conventional high bay luminaires
Areas of application
- Replacement for high bay luminaires with mercury vapor or metal halide lamps
- Warehouses, logistic halls
- Industry
- Sports facilities
- High ceiling (e.g. in shopping malls, airports, commercial buildings, lobbies)
Product features
- Sensor for daylight and motion detection for mounting heights of ~ 4 m to ~12 m
- Multi Lumen: lumen steps selectable
- Different luminous flux and beam angle for mounting heights
- High luminous efficacy: up to 195 lm/W
- Lifetime (L80/B10): up to 100,000 h (at 35 °C)
- Type of protection: up to IP65
- Impact resistance: IK04
Equipment / Accessories
- Sensor and mounting hook included
- Mounting brackets for surface mounting and remote control available as separate accessory
Safety advice
- All electrical connections must be made by a qualified person.
- Terminal block not included. Installation must be made by a qualified person.
- Caution, risk of electric shock.
- Product in protection class I. All electrically conductive, metallic housing parts that can absorb voltage during operation or during maintenance in the event of a fault must be continuously connected to the protective earthing conductor.
- To reduce the risk of strangulation the flexible wiring connected to this luminaire shall be effectively fixed to the wall if the wiring is within arm’s reach.
References / Links
- For Guarantee see
