LS P -1500/930/5

LS P -1500/930/5

Цена по запросу

Уточните цену и наличие у менеджера

Позвонить

Артикул: 4058075707658 Категория:
Product benefits
  • Great scope of design options due to long and flexible LED strips
  • Easy installation, no tools required for connection
  • Easy mounting on many smooth surfaces thanks to self-adhesive tape at the back
  • Maximum flexibility due to large range of accessories
  • Simple connection thanks to integrated cables on both sides
Areas of application
  • General indoor illumination
  • Industry
  • Offices, retail outlets and conference rooms
  • Architecture lighting
  • Decorative illumination
Product features
  • Flexible and cuttable LED strip
  • Smallest cuttable unit: 55.56 mm
  • Lifetime (L70/B50): up to 50,000 h at Tc max.: 80°C
  • Luminous flux: 1500 lm/m
  • Very good color rendering index Ra: > 90
  • Initial color consistency: < 3 SDCM
  • Large range of color temperatures: from warm white to cool daylight
  • Dimmable with suitable drivers, see also
Equipment / Accessories
  • Connectors, profiles and covers for several mounting options available
GTIN

4058075707658
Nominal wattage

60.00 W
Nominal voltage

24 V
Nominal current

2500 mA
Luminous flux

6600 lm
Luminous efficacy

121 lm/W
Color temperature

3000 K
Light color (designation)

Warm White
Color rendering index Ra

> 90
Standard deviation of color matching

‹3 sdcm
Beam angle

120 °
Height

1.50 mm
Product weight

95.00 g
Ambient temperature range

-20…+55 °C
Temperature range at storage

-20…+80 °C
Type of protection

IP00
Dimmable

Yes 1)
Minimum rate of recycled material in packaging

80 % 1)
Minimum percentage of recycled content in the product

0 % 1)
Product recyclability

Mostly recyclable product 1)
Packaging recyclability

Mostly recyclable packaging 1)
List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage

No
Contains substances of very high concern in concentrations greater than 0.1% by mass percentage

No
Mounting location

All surfaces
Protection class

III
Length

5000.00 mm
Width

8.00 mm
Quantity of precious metals

Contains at least 10 mg
Quantity of rare earths

Contains at least 1 mg
Construction wattage

60.00 W
Type of current

DC
Maximum temperature at tc test point

80 °C
Cable length

500.000
Input voltage range

23…25 V
Prewired

Yes
Conductor cross section

0.5 mm²
Light color LED

Warm White
Rated beam angle (half peak value)

120.00 °
Number of LEDs per module

720
Nominal lamp life time

50000 h
Energy class of contained light source

E
Nominal wattage per meter

12 W
Luminous flux per meter

1455 lm
Number of LEDs per meter

144
Lowest bending radius

30,0 mm
Self-adhesive

Yes
Number of LEDs per smallest unit

8
Length – smallest unit

55.56 mm
LED pitch

6.94 mm
Salt mist resistance acc. IEC 60068-2-52

No
UV resistance acc. IEC 60068-2-5

No
Short pitch

Yes
