Submarine Integrated PRO Special 120 cm 36 W EU Plug

Submarine Integrated PRO Special 120 cm 36 W EU Plug

Цена по запросу

Уточните цену и наличие у менеджера

Позвонить

Артикул: 4099854870958 Категория:
Product benefits
  • Easy installation and linking thanks to cover that can be simply opened​
  • Very homogenous light
Areas of application
  • Basements, garages, warehouses
Product features
  • LED integrated Damp-proof luminaire for mains voltage operation with EU Plug and Switch
  • Dust-protected and jet-proof (IP65)
Equipment / Accessories
  • Equipped with 2 m cable, EU plug and dust- and jet-proof switch
Safety advice
  • All electrical connections must be made by a qualified person.
  • To reduce the risk of strangulation the flexible wiring connected to this luminaire shall be effectively fixed to the wall if the wiring is within arm’s reach.
  • Caution, risk of electric shock.
GTIN

4099854870958
Nominal wattage

36.00 W
Nominal voltage

220…240 V
Nominal current

170.000 mA
Luminous flux

4320 lm
Luminous efficacy

120 lm/W
Color temperature

4000 K
Light color (designation)

Cool White
Color rendering index Ra

> 80
Standard deviation of color matching

< 5 sdcm
Photobiological safety group acc. to EN62778

RG0
Beam angle

120 °
Height

50.00 mm
Product weight

830.00 g
Product color

White
Housing color

White
Body material

Polycarbonate (PC)
Ambient temperature range

-20…+40 °C
Temperature range at storage

-40…80 °C
Type of connection

Plug type C (EU)
Type of protection

IP65
Dimmable

No
Lifespan L70/B50 at 25 °C

40000 h 1)
Standards

CE
Minimum rate of recycled material in packaging

80 % 1)
Minimum percentage of recycled content in the product

0 % 1)
Product recyclability

Mostly recyclable product 1)
Packaging recyclability

Mostly recyclable packaging 1)
List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage

No
Contains substances of very high concern in concentrations greater than 0.1% by mass percentage

No
Replaceable light source

No
Mounting type

Surface
Mounting location

Ceiling
Protection class

II
Ball shot safe

No
With light source

Yes
Cover material

Polycarbonate (PC)
Luminaire with limited surface temperature, "D sign"

No
Mains frequency

50…60 Hz
Inrush current

50.8 A
Inrush current time Th50

104 µs
Power factor λ

> 0.5
Total harmonic distortion

< 20 %
Operating mode

Mains voltage
Glow Wire Test according to IEC 60695-2-12

850 °C
Replaceable light source (EPREL)

Not replaceable
Total luminous flux of contained light sources

5000 lm
Max. number of luminaires per miniature circuit breaker B16

14
Max. number of luminaires per miniature circuit breaker C10

11
Max. number of luminaires per miniature circuit breaker C16

18
Protection class IK (shock resistance)

IK08
Length

1180.00 mm
Width

79.00 mm
