| GTIN |
4099854406751
|
| Nominal wattage |
28.3 W / 24.0 W / 21.4 W / 17.3 W / 14.0 W
|
| Nominal voltage |
220…240 V
|
| Nominal current |
200/175/150/125/100 mA
|
| Luminous flux |
4640 lm / 3900 lm / 3460 lm / 2810 lm / 2260 lm
|
| Luminous efficacy |
164 lm/W / 163 lm/W / 162 lm/W / 161 lm/W
|
| Color temperature |
4000 K
|
| Light color (designation) |
Cool White
|
| Color rendering index Ra |
≥80
|
| Standard deviation of color matching |
< 4 sdcm
|
| Flickering metric (Pst LM) |
< 1
|
| Stroboscope effect metric (SVM) |
< 0.4
|
| Photobiological safety group acc. to EN62778 |
RG1
|
| Beam angle |
120 °
|
| Height |
68.00 mm
|
| Product weight |
1410.00 g
|
| Product color |
Grey
|
| Housing color |
Grey
|
| Body material |
Polycarbonate (PC)
|
| Ambient temperature range |
-25…+40 °C
|
| Temperature range at storage |
-25…+80 °C
|
| Type of connection |
Screwless terminal, 3-Pole
|
| Type of protection |
IP65
|
| Dimmable |
No
|
| Lifespan L70/B50 at 25 °C |
100000 h 1)
|
| Number of switching cycles |
100000
|
| Minimum rate of recycled material in packaging |
80 % 1)
|
| Minimum percentage of recycled content in the product |
0 % 1)
|
| Product recyclability |
Mostly recyclable product 1)
|
| Packaging recyclability |
Mostly recyclable packaging 1)
|
| List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage |
No
|
| Contains substances of very high concern in concentrations greater than 0.1% by mass percentage |
Yes
|
| Replaceable light source |
Yes
|
| List of substances of very high concern in concentrations greater than 0.1% in mass percentage |
Lead (7439-92-1), 2-(2H-benzotriazol-2-yl)-4-(1,1,3,3-tetramethylbutyl)phenol (3147-75-9)
|
| Mounting type |
Suspended/Surface
|
| Mounting location |
Ceiling
|
| Protection class |
I
|
| Mercury content |
0.0 mg
|
| Ball shot safe |
No
|
| Type of emergency operation test |
None
|
| With light source |
Yes
|
| Cover material |
Polycarbonate (PC)
|
| Luminaire with limited surface temperature, "D sign" |
Yes
|
| Mains frequency |
0/50/60 Hz
|
| Inrush current |
8.1 A
|
| Inrush current time Th50 |
554 µs
|
| Power factor λ |
> 0.90
|
| Total harmonic distortion |
< 20 %
|
| Operating mode |
Integrated LED driver
|
| Glow Wire Test according to IEC 60695-2-12 |
850 °C
|
| Max. number of luminaires per miniature circuit breaker B16 |
26
|
| Max. number of luminaires per miniature circuit breaker C10 |
28
|
| Max. number of luminaires per miniature circuit breaker C16 |
42
|
| Protection class IK (shock resistance) |
IK08
|
| Length |
1200.00 mm
|
| Width |
82.00 mm
|
| Application environment |
Indoor
|
| Added function |
EVERLO
|
| Lifespan L80/B10 at 25 °C |
100000 h 1)
|
| Light emitting surface material |
Polycarbonate (PC)
|
| Output current |
200 mA
|
| Lifespan L90/B10 at 25 °C |
61000 h
|
| 14 W |
161 lm/W
|
| Low flicker |
Yes
|
| RAL Color (most similar) |
RAL 9018
|
| ECG - Output ripple current |
< 5 %
|
| Type of Emergency Lighting (EL) |
EL certified driver (0Hz / DC operation) for central battery operation included
|
| 24 W |
163 lm/W
|
| 28,3 W |
164 lm/W
|
| 21,4 W |
162 lm/W
|
| 17,3 W |
162 lm/W
|
