| GTIN | 4052899557949 |
|---|---|
| Nominal wattage | 180.00 W |
| Nominal voltage | 12…24 V |
| Height | 20.00 mm |
| Product weight | 71.00 g |
| Product color | White |
| Body material | Plastic |
| Ambient temperature range | -20…+45 °C |
| Temperature range at storage | -25…85 °C |
| Type of protection | IP20 |
| Dimmable | Yes |
| Standards | Acc. to EN 550 |
| Minimum rate of recycled material in packaging | 80 % 1) |
| Minimum percentage of recycled content in the product | 0 % 1) |
| Product recyclability | Mostly recyclable product 1) |
| Packaging recyclability | Mostly recyclable packaging 1) |
| List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage | No |
| Contains substances of very high concern in concentrations greater than 0.1% by mass percentage | No |
| Protection class | III |
| Mains frequency | 0 Hz |
| Length | 172.00 mm |
| Width | 42.00 mm |
| Type of connection, output side | Screw terminal |
| Quantity of precious metals | 0 mg |
| Quantity of rare earths | 0 mg |
| Maximum temperature at tc test point | 65 °C |
| Input voltage DC | 12/24 V |
| ECG lifetime | 50000 h 1) |
| Dimming range | 0…100 % |
| Dimming interface | DMX |
| Cable cross-section, output side | 0.5…1.5 mm² |
| Permitted rel. humidity during operation | 5…85 % 1) |
| Cable cross-section, input side | 0.5…1.5 mm² |
| Wire preparation length, input side | 10 mm |
| Mounting hole spacing, length | 164,0 mm |
| Overheating protection | Yes |
| Overload protection | Yes |
| Short-circuit protection | Yes 1) |
| Nominal output power | 182 W |
| Wire preparation length, output side | 10 mm |
| Nominal output voltage | 12…24 V |
| ECG efficiency | 95 % 1) |
| Device power loss | 4 W 2) |
| Galvanic isolation | Non isolated |
| Power loss in stand-by mode | < 0.5 W |
| Casing material | Plastic |
| Max.housing temperature in case of fault | 115 °C |
| Encapsulated | No |
| U-OUT (working voltage) | 24 V |
| Type of installation | Luminaire integration/Ceiling integration |
| No-load proof | Yes |
| Number of control outputs | 4 |
