| GTIN | 4008321065971 |
|---|---|
| Nominal wattage | 23.00 W |
| Nominal voltage | 220…240 V |
| Height | 22.00 mm |
| Product weight | 50.00 g |
| Body material | Plastic |
| Ambient temperature range | -15…+50 °C |
| Temperature range at storage | -40…+85 °C |
| Type of protection | IP20 |
| Dimmable | No |
| Standards | Acc. to EN 61347-2 |
| Minimum rate of recycled material in packaging | 80 % 1) |
| Minimum percentage of recycled content in the product | 0 % 1) |
| Product recyclability | Mostly recyclable product 1) |
| Packaging recyclability | Mostly recyclable packaging 1) |
| List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage | No |
| Contains substances of very high concern in concentrations greater than 0.1% by mass percentage | Yes |
| List of substances of very high concern in concentrations greater than 0.1% in mass percentage | Lead (7439-92-1) |
| Protection class | I/II |
| Mains frequency | 50 Hz |
| Inrush current | 14 A |
| Length | 80.00 mm |
| Width | 40.00 mm |
| Quantity of precious metals | 0 mg |
| Quantity of rare earths | 0 mg |
| Energy efficiency class | A3 |
| Maximum temperature at tc test point | 70 °C |
| Operating frequency | 35…45 kHz |
| Input voltage DC | 176…254 V |
| ECG lifetime | 30000 h 1) |
| Permitted rel. humidity during operation | 5…85 % 1) |
| Approval marks – approval | VDE |
| Mounting hole spacing, length | 72,0…75,0 mm |
| Max. cable length to lamp/LED module | 1.0 m / 0.5 m |
| Casing material | Plastic |
| Max.housing temperature in case of fault | 110 °C |
| U-OUT (working voltage) | 300 V |
| Max. ECG no. on circuit breaker 10 A (B) | 30 |
| Max. ECG no. on circuit breaker 16 A (B) | 50 |
| Starting time [PIM] | 1.5 s |
| End of lamp life safety shutdown | EOL T.2 |
| EEI – Energy Label | A3 |
